CMS 300G ECG Machine Three Channel

Specification:

• Electrocardiograph 3.5″ TFT Color LCD display shows the working status and ECG waveform.
• Safety Type : lass I, Type CF applied part, which has defibrillation-proof applied part
• Lead : Standard 12 leads
• input way: Floating and defibrillation protection
• Patient leak current <10µA
• Sampling rate: 1000Hz
• A/D conversion : 12bit
• Frequency response : 0.05Hz~150Hz (-3dB, + 0.4dB)
• time constant : >3.2s
• CMRR : >60dB, >100dB( Add filter)
• Noise level ?15µVp-p
• EMG interference filter 25Hz/35Hz (-3dB)
• AC filter :50Hz/60Hz (?20dB)
• Recording way : Thermal printing system (8spots/mm)
• Sensitivity 5mm/mV 10mm/mV 20mm/mV 40mm/mV Auto
• Paper speed: Auto-mode: 25mm/s, 50mm/s, Rhythm-mode:25mm/s, 50mm/s, Manual-mode:5mm/s, 6.25mm/s, 10mm/s, 12.5mm/s, 25&50mm/s
• Power supply: AC: 220V, 50Hz (110V, 60 Hz) DC: 7.4V, 3700 mAh rechargeable lithium battery
