EFG5K MEGASYS SPIRAL WIRE HOSE – SAE 1OOR13

Recommended For: Extremely high–pressure high–impulse applications. Exceeds all requirements of ISO 18752 Grade D (except for –24) and SAE 100R13 and performance requirements of EN 856 4SH (–16 and –20), EN 856 4SP (–10, and –12), EN 856 R13 and ISO 3862 Type R13 (–12, –16, –20, –24, –32). Compatible with biodegradable hydraulic fluids like polyolester, polyglycol and vegetable oil as well as standard petroleum–based fluids.
Superior impulse performance:tested to 1,000,000 impulse cycles with Gates couplings
Tube: Black, oil resistant synthetic rubber [Nitrile].
Reinforcement: Four [Six for (-20, -24, -32)] alternating layers of spiraled, high tensile steel wire.
Cover: Black, oil resistant, synthetic rubber [Polychloroprene]. With color coded layline. Also availble in MegaTuff cover in import range.
Temp. Range: -40°C to +121°C Coupling: GS (-6 to -20) & GSM ( -24 & -32) MEETS FLAME RESISTANCE ACCEPTANCE DESIGNATION “MSHA 2G”
